Product Description
EXCEPTIONAL BLADE LIFE
Proprietary backing steel preparation increases fatigue life and minimizes band breaks
Robust M42 high speed steel edge provides superior heat and wear resistance
EXTREMELY VERSATILE
Cuts a wide range of metals from low carbon steels to higher strength alloys
Advanced design enables production cutting of solids and structurals
Positive rake angle improves tooth penetration on saws with limited feed force
CONSISTENT PERFORMANCE CUT AFTER CUT
Unique tooth geometry and set minimizes noise and vibration from the very first cut
Smooth, straight cuts when cutting multiple pieces or wide cross sections
Specifications
TOOTH FORM WIDTH X THICKNESS | TPI | |||||
---|---|---|---|---|---|---|
IN | MM | 1.4/2.0 | 2/3 | 3/4 | 4/6 | 5/8 |
1 x .035 | 27 x 0.90 | ◆ | ◆♰ | ◆ | ◆ | |
1-1/4 x .042 | 34 x 1.07 | ◆ | ◆ | ◆♰ | ◆ | ◆ |
1-1/2 x .050 | 41 x 1.27 | ◆ | ◆ | ◆♰ | ◆ | ◆ |
2 x .050 | 54 x 1.27 | ◆ | ◆ | ◆ | ||
2 x .063 | 54 x 1.60 | ◆ | ◆♰ | ◆♰ | ◆ | |
2-5/8 x .063 | 67 x 1.60 | ◆ | ◆♰ | ◆♰ |
Applications
Primary
Solid Square / Rectangle
Sold Round
Plate
Secondary
I-Beam
Bundles
Tube
Angle Iron
Materials
- Carbon Steels
- Aluminum / Non-Ferrous
- Structural Steels
Secondary
- Alloy Steels
- Bearing Steels
- Mold Steels
- Tool Steels
- Stainless Steels
